Fuel Pressure Control Valve 0281007502 51 10320 0002 for Engine Common Rail DRV

Name: Fuel Pressure Control Valve 0281007502 51 10320 0002 for Engine Common Rail DRV
Brand: Henshine
Rating: 5.0 (21 reviews)

Availability:



Inquire

Model:
0281007502
Brand:
Henshine

Product Description

Product Description

0281007502

Fuel Pressure Control Valve

Fuel Pressure Regulator

0281007502

The fuel pressure control valve comprises a fuel-cooled solenoid valve.

The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains
a fuel pressure of about 100 Bar. When the valve is activated,
the force of the electromagnet aids the spring, reducing the opening of the valve
and so increasing fuel pressure. The fuel pressure control valve also acts as
a mechanical pressure damper, smoothing the high frequency pressure pulses

emanating from the radial piston pump when less than three pistons are activated.

for MAN TGS I (2019/01 - 2021/09)

for MAN TGS II (2020/02 - )

for MAN TGX I (2019/01 - 2021/09)

for MAN TGX II (2020/02 - )
